Introduction:
The camera adopts 1/3" SONY CCD sensor and DSP (digital signal processing) technology, with high-resolution and high sensitivity; The intensity of auxiliary lights and glare inhibition (Halo shrinkage) can be controlled by the key control. The intensity of auxiliary light is continuously adjustable; Five modes for choice, easy for testing and setting. Use special auxiliary lights, can capture clear and color image of lisence plate camera at night.
It applies to toll station, mount, entrances and exits of parking, traffic lights, and other monitoring sites, which can effectively capture license plates of passing cars and license plates of vehicles traveling on the road and vehicle identification.
Specification:
|
Image Sensor Device |
1/3" SONY HAD CCD |
|
Effective Pixels |
792(H) x 582(V) |
|
System of Signal |
PAL |
|
Horizontal Resolution |
650 TV Line (color ) |
|
Minimum Illumination |
0.01lux at F1.2 (color) |
|
S/N ration |
More than 48dB |
|
Electronic shutter |
1/50-1/10,000/sec |
|
Electronic shutter control |
On/Off Switch able |
|
Backlight Compensation |
On/Off Switch able |
|
Auto gain control |
On/Off Switch able |
|
Color |
color(if illumination < 1 Lux, auxiliary power on automatically) |
|
auxiliary lights available distance |
1m to 30m |
|
Automatic Iris drive |
f=8-20mm auto IRIS million hi-resolution lens |
|
Video output |
1.0vp-p ,75 ohm |
|
Power supply |
DC 12V |
|
Operating temperature |
-10 degree to +50 degree |
|
Dimension |
15.6 inch |
Installation:
1. Coaxial line.
2. Connect to DC12V power supply, if the upper casing is open, the indicator light is on.(D4).
3. When the image appears in the monitor, adjust the focus and Iris to get clear image.
4. Cover the upper casing, lock the back screw.
5. Fix the screw arbor of bracket well with holes at the bottom of camera.
Troubleshooting:
If there is any problem in the camera, please try to solve it as below, if not, contact us.
| Trouble | Solution |
| No video output | Check the power supply and power wire, video wire, check if the auto Iris is suitable. |
| Image is dark | Check the working mode and intensity of glare inhibition |
| Image is obscure | Check the lens surface and focus if it is well focusing well. |
| Image whitish. | Adjust DC-LEVEL drive output level |
| Image flashing | Adjust DC-LEVEL drive output |
Notice:
Please use it in clean, dry, little dust environment to lengthen lifespan.
Don’t use it in environment that temperature >50 degree, handle with care.
Camera control and setting
This camera is working at five different modes, select different working mode by key UP/DOWN. Or through RS485.(not standard equipment)
- Five modes for choosing:
Mode 1) 120km/hour
Mode 2) 80 km/hour
Mode 3) 40 km/hour
Mode 4) Standard mode
Mode 5) Glare inhibition mode - thunder-proof design
Item Include:
- 1 x Road dedicated all in one camera
- 1 x Bracket
