Details
DVR Feature:
- H.264 compression algorithm ideal for standalone DVR
- Support 4CH Playback at same time
- Real-time live display for D1, Real-time recording with CIF or 15FPS with D1
- Pentaplex function: live display, recording, playback, backup & remote access
- Multiple control methods: Front panel, remote controller, USB mouse, network controller.
- Multiple recording modes: manual recording, schedule recording, alarm recording, motion detection recording, and pre-recording.
- Ethernet interface is provided for realizing remote monitoring, remote playback, acoustic monitoring, remote setting.
- Alarm triggering buzzer, PTZ preset, E-mail, multiple channel recording.
- Easy backup methods: USB devices, network downloads.
- Support all channel playback at the same time, and searching according to time or event(alarm, manual and schedule)
- Multi-Language selectable: English, Italian, Turkish, Thai, Russian, Japanese, French, Portuguese, Spanish, Hebrew, Traditional Chinese, Chinese, Polish, Korean, Persian, German, Srpski, Dutch, Macedonian, Czech, Latvian, Greek, Vietnamese, Romanian
- Support remote view with Mobile Phone(Windows CE\Symbian\Iphone\ Blackberry\ Android)
DVR Specification:
| System | Main processor | Industry level embedded microprocessor |
| Operation system | Embedded LINUX operation system | |
| System resource | synchronous multi-channel recording, synchronous multi-channel sub-code stream, synchronous multi-channel playback, synchronous network operation | |
| Interface | Operation interface | 16 bit true color graphical menu interface, mouse operation supportive |
| display | 1/4 | |
| Video | Surveillance image quality | PAL: 704 x 576 NTSC:720 x 480 |
| Recording image quality | CIF PAL: 352 x 288 NTSC:360 x 240 D1 PAL: 704 x 576 NTSC:720 x 480 |
|
| Image compression | H.264 | |
| Image control | 6 options | |
| Recording frame rate(each channel) | CIF PAL: 25FPS NTSC:30FPS D1 PAL: 12FPS NTSC:15FPS |
|
| Image motion detect | multiple detection areas, multiple sensitivity | |
| Audio | Audio compression | G711A |
| Talk-back | supportive | |
| Recording And Playback |
Recording mode | manual >alarm>motion detect>timing |
| Local playback | Single channel playback, All channels playback | |
| Recording look-up mode | Time searching, calendar searching, affair searching, channel searching, information searching | |
| Storage And Backup |
Hard disk capability for each channel | Audio: 28.8Mbytes/hour Video:80~250Mbytes/hour |
| Recording storage | Hard disk, network | |
| Backup mode | Network, USB | |
| Port | Video input | 4 CH BNC |
| Video output | 1 CH BNC, 1 CH VGA | |
| Audio input | 4 CH RCA | |
| Audio output | 1 CH BNC | |
| Network port | RJ45 10M/100M adoptive Ethernet network port | |
| PTZ control port | 1 RS485 | |
| USB port | 2 USB ports(with USB backup and USB mouse) | |
| Hard disk port | 1 SATA port with 2TB hard disk(The Item Doesn't Contain Hard Disk) | |
| Other | Power supply | 12V/3A external power supply |
| Power consume (without hard disk) |
<10W | |
| Working temperature | 0 degree to +55 degree | |
| Working humidity | 10%-90% | |
| Air pressure | 86kpa-106kpa | |
| Installation | Frame installation, platform installation |
Camera Specification:
| Image Sensor | 1/3 Color CCD |
| Effective pixels | PAL: 512*582 NTSC: 512*492 |
| Resolution | 420TVL |
| Color/BW | Color |
| System of Signal | PAL/NTSC |
| Minimum Illumination | 0.5 Lux/F1.2 |
| Synchronizing System | Internal |
| S/N Ratio | >50dB |
| Auto Electronic shutter | 1/50~1/100,000SEC ON/OFF |
| Video output | 1.0Vp-p 75 ohm BNC |
| Lens | Board Lens 3.6mm |
| IR Range | 24 PCS IR Leds, 20 Meter IR distance |
| Power supply | DC12V |
| Power consumption | 300mA |
| Operation temperature | -10~+50 Celsius |
| Storage temperature | -30~+80 Celsius |
| Dimensions | 110(D)*75(H) mm/2.5 Inch |
Item Include:
- 1 x 1 x 4CH H.264 Real-time Recording Standalone Network DVR
- 1 x DVR Power Supply
- 1 x USB Mouse
- 1 x Remote Control
- 4 x 1/3 CCD Color 420TVL 3.6mm Indoor IR CCTV Camera
- 4 x 18M Video Cable and DC Cable
- 1 x 5 Way power cable spiliter
- (The Item Doesn't Contain Hard Disk)
